So What Is The SAM Unit?
Essentially it is a fuse box with internal relays and a microprocessor that controls almost all of the electrical functions of the car. The processor is flashable so it can be taught new tricks by way of a TAN code, these tricks include paddle gear shift, auto door locking, automatic gear change, day time running lights, cruise control etc.
What Does SAM Stand For?
Signal Acquisition & Actuation Module.
Where Is It?
It can be found at the top of the footwell, passenger side of a RHD smart city coupe/cabrio, drivers side of a LHD smart city coupe/cabrio and the drivers side of a Roadster.
What Does It Look Like?
Just a plain boring black box with fuses pushed into the front. Although the SAM units all look the same, the new 452 internals are slightly different.
What About The Bits We Can’t See?
The top side is where most of the wiring goes to, there are 10 connections and a positive input. All inputs are labled. Each circuit has its own earth point around the car.
There Is Something Missing
Damn right, Relays. Most cars have relays in the fuse box, these control the horn, wipers, indicators, lights etc. The relays visible on the smart are for the fog light and heated seats.
How Does That Work Then?
No different except in this case the relays are actually inside the SAM unit.
Inside The SAM Unit
Remove the three Torx10 screws.
Unclip all the plastic clips around the outside
With the top off you see the main fuse connections
With it removed from the box you see the relays and connectors
The board is in 4 parts and is bent around on itself, you can see the cracks between the tracks but this is normal. The tracks are OK.
PCB 1, 2 and 3 fold open and a flat plastic retainer can be removed
PCB 2 is populated with the microprocessor and many small relays
This shows the main functions of the relays on PCB 1
This shows the single relay on the back of PCB 3
And there are 2 relays over on PCB 4.
What Do The Relays Power?
Work in progress
Relay Number |
Part Number | SAM Connections | Fuses | Sends Power To… |
1 | Tyco V23076-A3001-C132 | N11-1 pin 3. N11-5 pin 10 & 12 |
8, 9, 10 | Evap purge valve. Z36 & Z35 |
2 | Fujitsu 51ND10-W1 | N11-5 pin 3 | Front wiper motor | |
3 | Fujitsu 51ND10-W1 | N11-5 pin 2 | Rear wiper motor | |
4 | Tyco V23076-A3001-D142 | N11-6 pin 2 | 32 | Secondary air injection pump |
5 | Tyco V23076-A3001-C132 | N11-6 pin 1 | 1 | Starter motor |
6 | Tyco V23076-A3001-C132 | N11-4 pin 2 | Z24 | |
7 | Tyco V23076-A3001-C132 | N11-2 pin 2 | Rear window and side mirror heater | |
8 | Fujitsu 51ND10-W1 | N11-2 pin 6 & 8 | Soft top motor(s) | |
9 | Tyco V23072-C1061-A408 | N11-3 pin 8 & 9 | 24, 25 | High beam headlights |
10 | Tyco V23072-C1061-A408 | N11-3 pin 6 & 7 | 22, 23 | Low beam headlights |
11 | Fujitsu 51ND10-W1 | N11-5 pin 11 & 12 | 5, 11, 12, 13, 14, 15, 16 |
ECU, light switch, speedo, dash buttons, OBD, CD, interior light, fog lights, ESP controller, AC, charge/intercooler, fuel pump. |
12 | Fujitsu 51ND10-W1 | N11-3 pin 10 N11-5 pin 7 & 9 |
6, 7 | Fuel pump, parking lights, boot release, rear lights |
13 | Tyco V23076-A3001-C132 | 3, 4 | Heater fan, heated seats, power windows. |
|
14 | NAIS ACT512 B02 | N11-10 pin 4 & 5 | 31 | Central locking |
15 | NAIS ACT512 B02 | N11-10 pin 7 N11-10 pin 6 |
15 31 |
Intercooler or Chargecooler Horn |
16 | Omron G8N-1S | N11-10 pin 8 | Boot release |
No User Servicable Parts Inside
You can say that again, if you get water in this there is nothing that can be done. There is nothing you can take out or change, everything is soldered directly to the PCBs.
What About Microchips?
There are surprisingly few IC packages inside the SAM unit. The main one however is the Motorola MC9S12DG256C which is a 112 pin 16-bit device composed of standard on-chip peripherals including a 16-bit central processing unit (HCS12 CPU), 256K bytes of Flash EEPROM and a whole load of other stuff that means very little to me.
If you want to know more about this chip. Click here.
SAM connections
700cc Fortwo And Roadster
N11-1 | Wire Colors | Connection | Fuse |
1 | Black Yellow/White Black | Window switches | 4 |
2 | Black Red | Heater blower motor | 3 |
3 | Black Yellow | AirCon connections | 8 |
4 | Pink Red | Wiper stalk and relay | 2 |
5 | Violet | Front fog lights | 13 |
6 | Red Black | ESP controller | 14 |
7 | Pink | Radio | 12 |
8 | Master engine relay | 10 | |
N11-2 | Wire Colors | Connection | Fuse |
1 | Brown Green | ECU (MEG unit) | 9 |
2 | Black | Wing mirror and rear window heater | 28 |
3 | Red White | Trip PC, OBD, speedo voltage | 11 |
4 | Red Green | Safety triangle | 11 |
5 | Brown | Earth | |
6 | Yellow | Soft top motor forward | 29 |
7 | Blue | ECU (MEG unit) | |
8 | Red White | Soft top motor reverse | 29 |
N11-3 | Wire Colors | Connection | Fuse |
1 | Rear window wiper | 17 | |
2 | Grey Green | ESP control unit | 18 |
3 | Red Yellow | Soft top switch, mirror adjuster switch | 19 |
4 | Blue | Trip PC, OBD, Speedo voltage | 20 |
5 | Blue Yellow | Cigarette lighter socket | 21 |
6 | Grey Red | Low beam | 22 |
7 | Blue Green | Low beam | 23 |
8 | White | High beam | 24 |
9 | White Blue | High beam | 25 |
10 | Red Black | Fuel pump | 16 |
11 | Blue Red | Brake light switch | 26 |
12 | Red White | ECU (MEG unit) | 24 |
N11-4 | Wire Colors | Connection | Fuse |
1 | Red Black | Ignition position 1 | |
2 | Red Blue | Connector Z24 | |
N11-5 | Wire Colors | Connection | Fuse |
1 | |||
2 | Rear window wiper | 17 | |
3 | Red | Wiper relay | |
4 | |||
5 | Brown | Earth | |
6 | Red White | Light stalk | 5 |
7 | Brown White | Boot release/window switch | 6 |
8 | Red Green | Interior lamp | 12 |
9 | Brown Yellow/Grey | Rear lights | 7 |
10 | Green | Connector Z36 | 30 |
11 | Black Pink | ECU (MEG unit) | 16 |
12 | Yellow Black | Connector Z35 | 10 |
N11-6 | Wire Colors | Connection | Fuse |
1 | Blue | Starter | 1 |
2 | Pink | Electric air pump | 32 |
N11-7 | Wire Colors | Connection | Fuse |
1 | Red White | Steering assist control | 35 |
2 | Red | ESP control unit | 34 |
3 | Red Black | Ignition main | 33 |
N11-8 | Wire Colors | Connection | Fuse |
1 | |||
2 | Brown White | Earth | |
3 | Grey Red | Wiper stalk | |
4 | Yellow White | Right door switch | |
5 | |||
6 | |||
7 | |||
8 | Yellow Green | Crash restraint | |
9 | Pink Red | Wiper motor | |
10 | Green Blue | Light stalk and trip PC | |
11 | Black Green | Cruise control stalk | |
12 | |||
13 | Brown | Earth | |
14 | White Black | Speedo CAN low | |
15 | Brown Red | Speedo CAN high | |
16 | Red | Steering wheel | |
17 | Yellow | Wiper stalk | |
18 | Blue Black | Door switch | |
19 | Yellow Red | Left door switch | |
20 | Green | Boot switch | |
31 | Blue | Blower multi-way switch | |
32 | Blue White | Soft top strut switch | |
33 | Pink Black | Soft top strut switch | |
34 | Grey | Handbrake switch | |
35 | White | Soft top power switch | |
36 | |||
37 | |||
38 | Grey Blue | Ignition position 2 | |
39 | White Black | ECU and steering assist CAN low | |
40 | Brown Red | ECU and steering assist CAN high | |
N11-9 | Wire Colors | Connection | Fuse |
1 | Black White | Left turn signal | |
2 | Grey | Aircon switch position 2 | |
3 | White Grey | OBD diagnostics | |
4 | Grey Blue | Interior lamp | |
5 | |||
6 | Pink | Fog lamp relay | |
7 | Pink Red | Cruise control stalk | |
8 | |||
9 | Blue Yellow | Auto light switch | |
10 | Green Blue | Cruise control stalk | |
11 | Black Green | Right turn signal | |
12 | Violet Blue | Hazard switch switch | |
13 | Blue | Central locking switch | |
14 | Violet | LIN Bus to Trip PC & auto light/wiper sensor | |
15 | |||
16 | Blue White | Wiper relay | |
17 | |||
18 | Blue Yellow | Auto light switch | |
19 | |||
20 | White | Key remote receiver | |
31 | Green | Aircon switch position 1 | |
32 | Black Red | Heated rear window switch | |
33 | Yellow Red | Light stalk | |
34 | Yellow | Light stalk | |
35 | Yellow Green | Light stalk | |
36 | Green Blue | Wiper stalk | |
37 | Yellow Black | Fog lamp switch | |
38 | Blue | Light stalk | |
39 | Black Green | Light stalk | |
40 | Red Green | Wiper stalk | |
N11-10 | Wire Colors | Connection | Fuse |
1 | Brown | Foot well earth | |
2 | White | Aircon compressor | |
3 | Brown Green | Coolant radiator fan | |
4 | White Blue | Door open signal | 31 |
5 | Grey Blue | Door closed signal | 31 |
6 | Blue Red | Horn | 31 |
7 | Yellow | Intercooler fan | 15 |
8 | Red | Boot open solenoid | 31 |
N11-11 | Wire Colors | Connection | Fuse |
1 | Red | 12 volt from battery |
