600cc 450 Fuse Layout

Mod Description
Mod Details
PremiumNo Difficulty Mod ID219 CreditEvilution For450 Fortwo Linkhttps://www.evilution.co.uk/mod/600cc-450-fuse-layout.htm Copy to Clipboard
Main
Main Fuse Box

Under the dashboard.

Relays and other info can be found here.

No Description Amp. Colour
1 Parking and tail lights, r., instrument panel illumination, license plate lights 7.5 A Brown
2 Parking and tail lights, l. 7.5 A Brown
3 Front fog lamps 15 A Blue
4 Rear fog lamps 7.5 A Brown
5 Low beam lights, r., with headlight range adjuster 7.5 A Brown
6 Low beam lights, l., with headlight range adjuster 7.5 A Brown
7 High beam lights, r., with highbeam adjuster 7.5 A Brown
8 High beam lights, l., with highbeam adjuster 7.5 A Brown
9 Ignition coil, starter 25 A Neutral
10 Indicator lamp, brake lights 15 A Blue
11 Radio, CD changer, instrument cluster, tachometer, backup light, seat sensor, OBD 15 A Blue
12 Power socket / Cigarette lighter socket 15 A Blue
13 Interior illumination, rear diagnostic socket 15 A Blue
14 Radio, CD changer 15 A Blue
15 Instrument cluster, remote control receiver, central locking, anti-theft alarm, remote tailgate unlocking switch 7.5 A Brown
16 Central locking actuators, safety unit, clock, horn, lower interior light, remote tailgate unlocking motor 15 A Blue
17 Rear window wiper 15 A Blue
18 MCO softop 25 A Neutral
19 MCO softop 25 A Neutral
20 ECU (petrol only) 7.5 A Brown
21 Rear window heater, engine fan, mirror heaters 30 A Green
22 Wiring system 40 A Orange
23 Heater blower 20 A Yellow
24 Electric windows 30 A Green
25 Windscreen wiper, washer pump, electric mirrors 20 A Yellow
26 ABS, ECU, airbag control unit, ZEE unit 7.5 A Brown
27 ABS control unit 50 A Red
Auxiliary (Secondary) Fuse Box

Under the carpet, under the left seat.

Number Description Amp Colour
F1 Intercooler Fan, AC compressor 15A Blue
F2 Fuel Pump, Auto transmission 10A Red
F3 Injectors, ECU 15A Blue
F4 Lambda Sensor(s), Fuel tank evap valve 10A Red
